DJI MAVIC 3 MULTISPECTRAL
See More, Work Smarter
From $6,245 CAD
Effective aerial surveying needs to see the invisible. That's why Mavic 3 Multispectral has two forms of sight. It combines an RGB camera with a multispectral camera to scan and analyze crop growth with total clarity. Agricultural production management requires precision and data, and Mavic 3M delivers both.
Compact and Portable
Foldable for easy storage
Multispectral Camera
4 × 5MP
G/R/RE/NIR
RGB Camera
20 MP
4/3 CMOS, mechanical shutter
Safe and Stable
Omnidirectional Obstacle Avoidance
15km Transmission Distance
Precise Positioning
Centimeter-level RTK positioning
Microsecond-level time synchronization
Efficient Aerial Surveying
Up to 200 hectares per flight
Multispectral + RGB imaging system
Highly Integrated Imaging System
Newly upgraded imaging system with one 20MP RGB camera and four 5MP multispectral cameras (green, red, red edge, and near infrared). Enables applications such as high-precision aerial surveying, crop growth monitoring, and natural resource surveys.
RGB camera characteristics
4/3 CMOS
20MP image sensor
1/2000s
Fastest mechanical shutter speed
0.7s
High-speed burst when RGB camera is used
Sunlight Sensor
The built-in sunlight sensor captures solar irradiance and records it in an image file, allowing for light compensation of image data during 2D reconstruction. This results in more accurate NDVI results, as well as improved accuracy and consistency of data acquired over time.
RTK Module
Accurate images that
capture every pixel
Mavic 3M with RTK module for centimeter-level positioning. Flight control, the camera, and the RTK module sync in microseconds to accurately capture the location of each camera’s imaging center. This enables Mavic 3M to do high-precision aerial surveying without using ground control points.
Efficient and reliable battery life
Ultra-long battery life, fast bursts
43 minutes
Cruise time
200 hectare
A single flight can complete mapping
operations over an area of 200 hectares.
Fast Charging
100W Battery
Charging Hub
High-efficiency fast charging
88W fast charging
Aircraft
Stable signal, smooth image transmission
The O3 transmission integrates two transmitting signals and four receiving signals to support 15km ultra-long transmission distances.
Omnidirectional obstacle sensing, terrain-follow aerial surveying
The aircraft features multiple wide-FOV vision sensors that accurately detect obstacles in all directions for omnidirectional obstacle avoidance. The terrain-follow aerial surveying can be easily performed in steep-slope landscapes.
Applications
Orchard mapping
Mavic 3M allows terrain-follow aerial surveying of orchards, even on sloped landscapes. Produce high-resolution orchard maps, automatically identify the number of trees, distinguish trees from other obstacles or objects, and generate three-dimensional operation routes for spray drones.
Guide variable rate applications
The Mavic 3M is used to obtain multi-spectral images of crops. DJI Terra or the DJI SmartFarm Web can then generate NDVI and other vegetation maps, capturing differences in crop potential and generating prescription maps that allow spray drones to execute variable-rate application.
Intelligent field scouting
The Mavic 3M can carry out automatic field scouting. The field scout images can be uploaded to the DJI SmartFarm Web in real time through a 4G network. It can find abnormalities, such as emergence deficiencies, weed pressure, and crop lodging in a timely manner.
Environmental Monitoring and Natural Resources Survey
The Mavic 3M can also be used in environment and natural resource surveys, such as water enrichment monitoring, forest distribution surveys, urban green area surveys, and more.
Get In Touch
Have a question? Ready for a quote?
We’re here to help! Reach out to us today.
Specs
Net Weight (with propellers and RTK module:
951 g
Max Takeoff Weight:
1,050 g
Dimensions (Folded/Unfolded):
Folded (without propellers): 223×96.3×122.2 mm (Length×Width×Height)
Unfolded (without propellers): 347.5×283×139.6 mm (Length×Width×Height)
Diagonal Length:
Diagonal: 380.1 mm
Max Ascent Speed:
6 m/s (Normal Mode)
8 m/s (Sport Mode)
Max Descent Speed:
6 m/s (Normal Mode)
6 m/s (Sport Mode)
Max Flight Speed (at sea level, no wind):
15 m/s (Normal Mode)
Flying forward: 21 m/s, flying sideways: 20 m/s, flying backwards: 19 m/s (Sport Mode) [2]
Max Wind Speed Resistance:
12 m/s [3]
Max Take-off Altitude Above Sea Level:
6000 m (without a payload)
Max Flight Time (without wind):
43 minutes [4]
Max Hover Time (without wind):
37 minutes [4]
Max Flight Distance:
32 km [6]
Max Pitch Angle:
30° (Normal Mode)
35° (Sport Mode)
Max Angular Velocity:
200°/s
GNSS:
GPS + Galileo + BeiDou + GLONASS
(GLONASS is supported only when RTK module is enabled)
Hovering Accuracy Range:
Vertical: ±0.1 m (Vision Positioning enabled); ±0.5 m (GNSS Positioning enabled); ±0.1 m (D-RTK enabled)
Horizontal: ±0.3 m (Vision Positioning enabled); ±0.5 m (HD Positioning enabled); ±0.1 m (RTK enabled)
Operating Temperature:
-10° to 40° C (14° to 104° F)
Internal Storage:
N/A
Motor Model Number:
2008
Propeller Model Number:
9453F Enterprise Edition
Light Sensor:
Built-in module
Image Sensor:
4/3 CMOS
Effective Pixels: 20 MP
Lens:
FOV: 84°
Equivalent focal length: 24 mm
Aperture: f/2.8 to f/11
Focus: 1 m to ∞
ISO Range:
100–6400
Shutter Speed:
Electronic shutter: 8–1/8000 s
Mechanical shutter: 8–1/2000 s
Max Image Size:
5280×3956
Photo Shooting Mode:
Single shot: 20 MP
Timed: 20 MP
JPEG: 0.7 / 1 / 2 / 3 / 5 / 7 / 10 / 15 / 20 / 30 / 60 s
JPEG + RAW: 3 / 5 / 7 / 10 / 15 / 20 / 30 / 60 s
Panorama: 20 MP (original material)
Video Resolution:
H.264:
4K: 3840×2160 @ 30fps
FHD: 1920×1080 @ 30fps
Max Video Bitrate:
4K: 130 Mbps
FHD: 70 Mbps
Supported File System:
exFAT
Image Format:
JPEG / DNG (RAW)
Video Format:
MP4 (MPEG-4 AVC / H.264)
Image Sensor:
1/2.8-inch CMOS
Effective pixels: 5 MP
Lens:
FOV: 73.91° (61.2° × 48.10°)
Equivalent focal length: 25 mm
Aperture: f/2.0
Focus: Fixed Focus
Multispectral Camera Band:
Green (G): 560 ± 16 nm
Red (R): 650 ± 16 nm
Red Edge (RE): 730 ± 16 nm
Near Infrared (NIR): 860 ± 26 nm
Gain Range:
1x–32x
Shutter Speed:
Electronic Shutter: 1/30–1/12800 s
Max Image Size:
2592 × 1944
Image Format:
TIFF
Video Format:
MP4 (MPEG-4 AVC / H.264)
Photo Shooting Mode:
Single shot: 5 MP
Timelapse: 5 MP
TIFF: 2 / 3 / 5 / 7 / 10 / 15 / 20 / 30 / 60 s
Video Resolution:
H.264:
FHD: 1920 × 1080 @ 30fps
Video content: NDVI / GNDVI / NDRE
Max Video Bitrate:
Stream: 60 Mbps
Stabilization System:
3-axis mechanical gimbal (tilt, roll, pan)
Mechanical Range:
Tilt: -135° to 45°
Roll: -45° to 45°
Pan: -27° to 27°
Controllable Range:
Tilt: -90° to 35°
Pan: Uncontrollable
Max Control Speed (Tilt):
100°/s
Angular Vibration Range:
±0.007°
Sensing System Type:
Omnidirectional binocular vision system with an infrared sensor at the bottom of the aircraft
Forward:
Distance Measuring Range: 0.5 m to 20 m
Detection Range: 0.5 m to 200 m
Effective Obstacle Avoidance Speed: Flight speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 103°
Backward:
Distance Measuring Range: 0.5 m to 16 m
Effective Obstacle Avoidance Speed: Flight speed ≤ 12 m/s
FOV: Horizontal 90°, Vertical 103°
Lateral:
Distance Measuring Range: 0.5 m to 25 m
Effective Obstacle Avoidance Speed: Flight speed ≤ 15 m/s
FOV: Horizontal 90°, Vertical 85°
Upward:
Distance Measuring Range: 0.2 m to 10 m
Effective Obstacle Avoidance Speed: Flight speed ≤ 6 m/s
FOV: Front and rear 100°, Left and right 90°
Downward:
Distance Measuring Range: 0.3 m to 18 m
Effective Obstacle Avoidance Speed: Flight speed ≤ 6 m/s
FOV: Front and rear 130°, Left and right 160°
Operating Environment:
Front, Rear, Left, Right, Above: Surfaces with clear patterns and adequate lighting (> 15 lux, environments with normal indoor fluorescent light exposure)
Below: Surfaces with diffuse reflection material and a reflectivity of >20% (such as walls, trees, people, etc.); Adequate lighting (> 15 lux, environments with normal indoor fluorescent light exposure)
Video Transmission System:
DJI O3 Image Transmission Industry Edition
Live View Quality:
Remote Controller: 1080p / 30fps
Operating Band:
2.400–2.4835 GHz
5.725–5.850 GHz
Max Effective Signal Distance (Unobstructed, No Interference):
FCC: 15 km
CE: 8 km
SRRC: 8 km
MIC: 8 km
Max Transmission Distance (Obstructed):
Strong Interference (urban landscapes, residential areas, etc.):
1.5–3 km (FCC / CE / SRRC / MIC)
Medium Interference (suburban landscapes, city parks, etc.):
3–9 km (FCC), 3–6 km (CE / SRRC / MIC)
Weak Interference (remote fields, open farmland, etc.):
9–15 km (FCC), 6–8 km (CE / SRRC / MIC)
Max Download Speed:
15 MB/s (with DJI RC Pro Industry Edition)
Latency (Depending on Environment and Mobile Device):
Approximately 200 milliseconds
Antennas:
4 antennas (2 transmitting, 4 receiving)
Transmitter Power (EIRP):
2.4 GHz: <33 dBm (FCC), <20 dBm (CE / SRRC / MIC)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
Other:
Supports the DJI Cellular Module
Image Transmission System:
DJI O3 Image Transmission Industry Edition
Max Effective Signal Distance (Unobstructed, No Interference):
FCC: 15 km
CE: 8 km
SRRC: 8 km
MIC: 8 km
Operating Band of Image Transmission:
2.400–2.4835 GHz
5.725–5.850 GHz
Antennas:
4 antennas (2 transmitting, 4 receiving)
Operating Band of Image Transmission and Transmitter Power (EIRP):
2.4 GHz: <33 dBm (FCC); <20 dBm (CE / SRRC / MIC)
5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)
Wi-Fi Protocol:
802.11 a/b/g/n/ac/ax
Supports 2×2 MIMO Wi-Fi
Wi-Fi Operating Band:
2.400–2.4835 GHz
5.150–5.250 GHz
5.725–5.850 GHz
Wi-Fi Operating Band and Transmitter Power (EIRP):
2.4 GHz: <26 dBm (FCC); <20 dBm (CE / SRRC / MIC)
5.1 GHz: <26 dBm (FCC); <23 dBm (CE / SRRC / MIC)
5.8 GHz: <26 dBm (FCC / SRRC); <14 dBm (CE)
Bluetooth Protocol:
Bluetooth 5.1
Bluetooth Operating Band:
2.400–2.4835 GHz
Bluetooth Transmitter Power (EIRP):
<10 dBm
Screen Resolution:
1920×1080
Screen Size:
5.5 inches
Screen Frame Rate:
60 fps
Screen Brightness:
1,000 nits
Touch-Screen:
10-point multi-touch
Battery:
Lithium-ion battery (5000 mAh, 7.2 V)
Charging Type:
100W Battery Charging Hub or USB charger with 12V or 15V specifications is recommended
Rated Power:
12 Watts
Storage Capacity:
Internal Memory (ROM): 64 GB
Supports microSD card usage to increase storage capacity
Charging Time:
Approx. 1.5 hours (using 100W Battery Charging Hub or 15V USB charger)
Approx. 2 hours (using 12V USB charger)
Approx. 2 hours 50 minutes (charging aircraft and remote together with 100W Hub)
Operating Time:
Approx. 3 hours
Video Output Port:
Mini-HDMI Port
Operating Temperature:
-10° to 40° C (14° to 104° F)
Storage Temperature Range:
<1 month: -30° to 60° C (-22° to 140° F)
1–3 months: -30° to 45° C (-22° to 113° F)
3–6 months: -30° to 35° C (-22° to 95° F)
6 months: -30° to 25° C (-22° to 77° F)
Charging Temperature:
5° to 40° C (41° to 104° F)
Supported DJI Aircraft:
DJI Mavic 3E
DJI Mavic 3T
DJI Mavic 3M
GNSS:
GPS + Galileo + GLONASS
Dimensions:
Antenna folded, no control sticks: 183.27 × 137.41 × 47.6 mm
Antenna unfolded, sticks installed: 183.27 × 203.35 × 59.84 mm
Weight:
Approx. 680 g
Model Number:
RM510B
Supported microSD Cards
Aircraft:
Please use a memory card with a speed rating of V30 or higher, or use a memory card from the recommended list.
Recommended microSD Cards
Remote Controller:
SanDisk Extreme PRO 64GB V30 A2 microSDXC
SanDisk High Endurance 64GB V30 microSDXC
SanDisk Extreme 128GB V30 A2 microSDXC
SanDisk Extreme 256GB V30 A2 microSDXC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 667x 64GB V30 A2 microSDXC
Lexar High-Endurance 64GB V30 microSDXC
Lexar High-Endurance 128GB V30 microSDXC
Lexar 667x 256GB V30 A2 microSDXC
Lexar 512GB V30 A2 microSDXC
Samsung EVO Plus 64GB V30 microSDXC
Samsung EVO Plus 128GB V30 microSDXC
Samsung EVO Plus 256GB V30 microSDXC
Samsung EVO Plus 512GB V30 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC
Aircraft:
SanDisk Extreme 32GB V30 A1 microSDHC
SanDisk Extreme PRO 32GB V30 A1 microSDHC
SanDisk Extreme 512GB V30 A2 microSDXC
Lexar 1066x 64GB V30 A2 microSDXC
Kingston Canvas Go! Plus 64GB V30 A2 microSDXC
Kingston Canvas React Plus 64GB V90 A1 microSDXC
Kingston Canvas Go! Plus 128GB V30 A2 microSDXC
Kingston Canvas React Plus 128GB V90 A1 microSDXC
Kingston Canvas React Plus 256GB V90 A2 microSDXC
Samsung PRO Plus 256GB V30 A2 microSDXC
Capacity:
5000 mAh
Standard Voltage:
15.4 V
Max Charging Voltage:
17.6 V
Battery Type:
LiPo 4S
Chemical System:
Lithium Cobalt
Energy:
77 watt-hours
Weight:
335.5 g
Charging Temperature:
5° to 40° C (41° to 104° F)
Input:
100V to 240V (AC), 50Hz to 60Hz, 2.5A
Output Power:
100 Watts
Output:
Maximum output power of 100 Watts (total)
When both ports are used, the maximum output power of one interface is 82 W, and the charger will dynamically allocate the output power of the two interfaces according to load power.
Input:
USB-C: 5V to 20V, 5.0A
Output:
Battery Port: 12V to 17.6V, 8.0A
Rated Power:
100 Watts
Charging Type:
3 batteries on charging rotation
Charging Temperature:
5° to 40° C (41° to 104° F)
Dimensions:
50.2 × 40.2 × 66.2 mm (Length × Width × Height)
Weight:
24 ± 2 g
Interface:
USB-C
Power:
Approximately 1.2 watts
RTK Position Accuracy:
Fixed RTK:
Horizontal: 1 cm + 1 ppm
Vertical: 1.5 cm + 1 ppm
